Customer Challenge
Fixed Leading Edge components design change for new engine
A major aircraft OEM required a new engine mounting option for one of its aircraft series. The new engine along with weight optimized wing structures and aerodynamic improvements would reduce 14% fuel burn per seat. As the new engine is heavier and larger, redesign of wing structural components aroused.
The OEM sought for a partner to redesign fixed leading edge wing components and support certification.
Scope
- Fixed Leading Edge components static stress analysis and recommend design changes to accommodate new engine
Solution
- Static strength analysis
- Factoring analysis
- Identification of low Reserve Factor (RF) zones and develop approach methods to mitigate these low RFs
- Proposed design changes
Features
Features
- Integrated Design & Stress
- Support PDR, CDR approvals
- Release Certification dossiers:
- Sub-Spar and D-Nose
- FLE Ribs
Benefits
- Faster design improvement achieved
- Improved aircraft performance
Results
- On-time delivery of improved design Identified 7 critical zones for design changes
- Deliverables were FTR (First Time Right) 189KG
- Weight reduction per wing set
