Scope
- Scope of the project is to integrate the TSUI into two mobile surgery systems. It covers all functional, performance, test, service, manufacturing and miscellaneous requirements (non-functional requirements) which must be designed and tested before the unit can be functionally integrated into two Mobile Surgery Systems
Solution
- Stand electrical packaging/cabling adjustment to accommodate the HDBaseT Transmitter box without disturbing the position of the Splitter Box
New bracket Design to mount HDBaseT Transmitter box - Stand connector panel layout adjustment to add the TSUI port
- Design of Internal Cables like Power Cable, HDMI, LAN & USB Cables
- Standardization of cables across different surgery systems
- Creating ECR ,ECO ,DCO and DHF and assigning workflow in Agile for review and approval.
- Supplier interaction and Prototyping of cables and Bracket
- Packaging Design and FRU Kit
- Validation and Testing
- Production tooling, production test
- Documentation (Unit Design Specification, Unit Test Report, Assembly Instruction, Parts Service Manual, Parts Installation Manual)
Benefits
- End to End solution with validation and testing
- Modular design with provision for HDBT mounting which will yield cost benefit
- The entire unit can be fitted with in 1 hour against the requirement of 1.5 Hours
Features
- Modular design
- Complies with medical compliance
- Prototype development and Unit testing
