Customer Challenge
We needed to help our client to analyse the temperature distribution within a saloon as the treated air is delivered from a heating/cooling system.
This analysis was needed to ensure the system’s suitability for end, middle and double deck cars
Scope
- To analyse the temperature distribution within the saloon as the treated air is delivered from the heating/cooling system
Solution
- Using NX9.0 software, we created fluid volumes based on provided geometry specifications.
- Our software expertise allowed us to test the air distribution within the cars under a range of environmental conditions.
- We were able to visualise flow using contours and vectors. This allowed all stakeholders involved to see and test temperature distribution.
Features
- We used the latest STAR CCM+ and NX9.0 software for simulation, allowing for easy-to-understand visualization and measurement.
Benefits
- The customer was able to see the potential distribution and pressure drop of the treated air through the car’s ducting
- They were able to measure comfort within the saloon and determine the best summer and winter configurations.
- Temperature distribution within the double deck saloon was assessed across 14 operating points to determine system effectiveness.
